InsulFast™ T4 Insulation Fasteners (Copy)

Insulation Fasteners for Concrete Masonary and Steel. WHITE Anchors are designed for masonry, concrete and hollow block substrates. BLACK Anchors are designed for timber and steel stud substrates. 1x Pulsa 800 Fuel Cell is included with every carton of 500 fasteners.

Soft Insulation Thickness (mm)

25-30
T4IG625-1,T4IG625B-1
38-45
T4IG638-1
50-55
T4IG650-1,T4IG650B-1
60-65
T4IG663-1
75-80
T4IG675-1,T4IG675B-1
100-110
T4IG6100-1

Colour

Black
T4IG625B-1,T4IG650B-1,T4IG675B-1
White
T4IG625-1,T4IG638-1,T4IG650-1,T4IG663-1,T4IG675-1,T4IG6100-1

Before visiting a Stockist or Service Centre, contact them to ensure product availability.

PART NUMBER:

ADD TO TOOLBOX iEXPERT

-+PRODUCT INFORMATION

Click on the column headings to reorder the table.

ITEM CODE	Soft Insulation Thickness (mm)	Colour	Length (mm)	Order Qty
T4IG625-1	25-30	White	25-100	500
T4IG625B-1	25-30	Black	25-100	500
T4IG638-1	38-45	White	25-100	500
T4IG650-1	50-55	White	25-100	500
T4IG650B-1	50-55	Black	25-100	500
T4IG663-1	60-65	White	25-100	500
T4IG675-1	75-80	White	25-100	500
T4IG675B-1	75-80	Black	25-100	500
T4IG6100-1	100-110	White	25-100	500

STEEL ZINC PLATED

STAINLESS STEEL

GALVANISED STEEL

ADD

The selected variations added in the toolbox. Please view the items in the toolbox.

-+SPECIFICATIONS

Fastener Body Material	High Density Polyethylene (HDPE)
Holding Diameter	60mm
Drive Pin Material	Carbon Steel
Drive Pin Plating	Mechanical Zinc Plate
Drive Pin Shear Strength	8.0kN
